Servo Stabilizer - Three Phase Oil Cooled
A voltage stabilizer is an Electrical & electronic device that supplies a consistent output
voltage irrespective of input supply (Depending on Input Range). It protects
Electric/electronic appliances from under and over /under voltage supply.
What is the main function of the Servo Stabilizer? A Servo voltage stabilizer functions (Through Servo Motor) to automatically maintain a constant level (+/-1% Variation) of the voltage for our electrical appliances
Product Description
Servo stabilizers are designed and manufactured with the latest technology and stringent
quality measures to safeguard all types of electrical appliances from crucial
voltage fluctuations. It does never be a pay, when it comes, your valuable equipment
shocks you with a breakdown pay.
Each Electrical/Electronic/Electromechanical equipment have designed for a particular
Working voltage. A high fluctuation in AC supply is a common phenomenon in the whole
country. The fluctuation range is varying one place to another place depending on the
load
ON/OFF. (In India designed single phase equipment 220V/230V/240V, 3 Phase Equipment
380V/400V/415V with 50HZ, But US/Japan Single Phase 110V/110V/120V, 3 Phase 200V/220V
with 60HZ).
Constant voltage is very important for the better Efficiency, safety, and long life of
equipment and appliances, Some Equipments can withstand plus or Minus 20% or10% or 5% or
2% Of rated Voltage.It is Depended on purely Equipment Manufacture
| Capacity | 3 KVA -1500 KVA Oil Cooled / 3 KVA -100 KVA Air Cooled |
| Input Range | 220V, 240V, 295V, 340V, 360V, 380V – 465V, 480V |
| Output Voltage | 400V AC adjustable between 380V-415V |
| Correction Rate | 25V / 35V / 60V / 85V Sec Phase to Phase |
| Protection | For Input & Output Over/Under Voltage/ Short Circuit/ Overload/ Single Phasing/Phase reverse |
| LED Indication | Input On, Output On, Output Low Cut Off, Output High Cut Off, Input Low Cut off, Input High Cut Off, Over Load, Single Phase Failure, Phase Reverse, Neutral to Earth Leakage. |
| System & Connection | Unbalance 4 Wires (RYB&N), Star Connected & Earth |
| Supply Frequency | 50HZ±5% |
| Output Regulations | 1% (No Load To Full Load) |
| Insulation | Class "F","H" |
| Metering | 3-7 Segment Led Display for Input / Output Voltage, Load Current, Supply Frequency, setting parameters, Sensitivity, High/Low cut off voltage, Overload Current limit, Earth to neutral leakage voltage limit / Above 75KVA LCD Display provided with error log |
| Ambient Teemperature | 45"C Maximum, Relative Humidity up to 90% |
| Output waveform | Same as Input |
| Overload Capacity | 120% Maximum |
| Type of Cooling | Oil / Air |
| Mode of System | Fully automatic |
| Output Control | Contactor Through Manual feather touch button. Optional for automatic (7 Sec to 3 Min) |
| Servo motor drive | Rugged AC Synchronous stepper motor |
| Input/Output Cabling | Up to 6KVA Connectors, above 9 KVA Hylam with bold nut, above 50KVA Hylam with AL Flat / CU Flat, Input / Output Cable glands provision and Double Earth Connecting Provision Provided |
| Efficiency | More than 98% |
| System Construction | As Per IS : 9815-1994 |
|
Note: Non-Standard Input and Output
ranges also available as per customer
requirements
|
|
- Engineering & Manufacturing (Railway, Oil & Gas, Construction)
- Metal Cutting (CNC&EDM)
- Textile & Apparel (Weaving, Knitting, Spinning, Dyeing & compacting)
- Hospitals, Labaratories & Bio Medicals
- Retail Showrooms, Restraurents
- IT
- Agriculture
- Fuel Stations
- Domestic Applications
Frequently Asked Questions
- Permanent Damage Equipment
- Winding Insulation Week, Equipment Drawn High Current
- Deratingof Equipment Life/Efficiency
- MD (Maximum Demand) Increases,PF also Effect
- Frequent Break Down Occurs
- Malfunction of Equipment
- Speed of Equipment Also Decreased
Manual booster Line Voltage Stabilizer Servo Stabilizer Static Stabilizer Constant
Voltage Transformer
Servo Motor control 25V to 100V/Sec
Able servo stabilizer Efficiency above 98% (Efficiency=output power/input
power*cosφ)
Output Low / High Voltage, Input Low/High Voltage, OverLoad, Short Circuit, Phase
reverse, Earth to Neutral leakage, Single phase failure.
The voltage sensing, correction With Each Phase Separate Motor control is done in
each phase independently with respect to the neutral is also called an unbalanced
type voltage stabilizer. Each Phase is different input voltage (Ex
R-200V,Y-210V,B-220V But All Output 230V±1%) / LTSupply this type is suitable.
Protections also sense each phase separately, single phase & Three phase both types
of load suitable
The voltage sensing any 2 Phase & correction All Phases with common Servo Motor
control is called as balanced type voltage stabilizers. All Phases Equal input
voltage (Ex RY-330,YB-330V,BR-330V),HT
/and OLTC with 3 Phase Load is suitable. Protections also sense each phase
separately. Single phase load is not suitable for this type of stabilizer.
Servo Stabilizer Consist of Servo Motor, Variac with Carbon Brush,
Buck-BoostTransformer, Servo Control PCB, Contactor/relay. In servo Stabilizer the
servomotors involved with help of PCB, AutoTransformer, and Buck Boost Transformer
there is a small delay in voltage correction. However, output voltage accuracy is
usually ±1% with an input voltage variation of upto10% to ±50%, ABLE is the one of
top Servo stabilizer manufacturers in India with a tolerance of +/- 1% with high/low
output voltage cut-off and overload cut-off. This ensures smooth operation and
longer life for the equipments.
Servo Stabilizer is main moving parts is dimmer, Dust Area the use appears in
Variac, So Variac is not moving smoothly due to dust (there is possible of getting
fire through sparking in dust area use Air Cooled), In dust area and Higher
capacities oil cooled servo stabilizer is suitable Ex. Textile Unit, Garment
Division, Foundry Unit, wood industries, and pattern shop.
Transformer Oil Grade IS 335, It is used only for Stabilizer Cooling Purpose
Depending on Usage 5 To 10 years Only Filtering is Required, but oil replacing 10 to
15 years only Depending on usages
- Every 6 Month Carbon Brush Check/ Replace
- Erery 3 Month Clean from dust
- Every 6 Month Motor Alignment /Variac Moment check
- Yearly Once Check All Bolt/ Nut
- Oil Cooled Stabilizer Check Carbon Brush / Oil every 2years
